The AUDAC WX802 8″ Wall Mounted Outdoor Installation Speaker ensures impactful sound in any outdoor location. Its IP55 rating means that is safe to use even when it rains. This is ensured with the use of a waterproof AWX-5 connector and other features.
This speaker creates powerful sound and deep bass with an 8″ loudspeaker and 1″ tweeter. It can be mounted both vertically and horizontally too. Take your outdoor spaces to the next level with the sound from the WX802.
AUDAC WX802 8″ Wall Mounted Outdoor Installation Speaker
- 2-way performance speaker suitable for outdoor installations
- IP55 rated so keeps out most dust and can withstand low-pressure jets of water
- Ensured outdoor safety with drain hole, special power coating and waterproof AWX-5 connector
- Delivers 70 Watts of power with a 1″ dome tweeter and an 8″ low-frequency loudspeaker
- Use with 16 Ohm systems or 70/100V PA systems
- Can be mounted both vertically and horizontally using attached bracket
Specifications
AUDAC WX802 8″ Wall Mounted Outdoor Installation Speaker
- Impedance: 16Ω
- Sensitivity(1W/1m):Â 89dB
- IP Rating:Â IP55
- Speaker Type:Â 2-way
- RMS Power:Â 70W
- Max. Power:Â 140W
- Connectors:Â Waterproof AWX-5 connector
- Crossover:
- Frequency:Â 2.4kHz
- Type:Â Passive built-in
- Drivers:
- HF:Â 1″
- LF:Â 8″
- Frequency:
- Range(-10dB):Â 50Hz – 20kHz
- Response(±3dB): 60Hz – 17kHz
- Sound Pressure(Max. W/1m):
- @ 100V:Â 106dB
- @ 16Ω: 108dB
- Dispersion:
- Horizontal: 110°
- Vertical: 110°
- Line Transformations Tappings:
- 1: 83Ω – 100 V / Not used – 70 V / 60 W
- 2: 167Ω – 100 V / 60 W – 70 V / 30 W
- 3: 333Ω – 100 V / 30 W – 70 V / 15 W
- Dimensions(WxHxD):Â 270 x 360 x 215mm
- Weight:Â 7.5kg
- Operating Temperature: -25°C 70°C
