The ADJ UB 6H is a 22.5-inch (.5 meter)professional grade indoor linear fixture powered by six 6W-Watt HEX (RGBAW+UV 6-IN-1) LEDs. Its bright chromatic 40-degree beam angle provides vibrant HEX color mixing designed for washing
stages, walls and dance floors. Its rugged casing with patent pending Quick Align end locking allows for a seamless output of light with no breaks of color.
The UB 6H features built-in Color Macros (built-in preset colors), 6 DMX Channel Modes, 0-100% dimming and variable speed strobe. Plus, it offers flexible programming from its on-board 4-Button LED DMX-512 menu, or from the ADJ UC-IR wireless remote (sold separately).
• 22.5-inch (.5 meter) indoor Linear Bar with 6x6W Ultra bright RGBAW+UV HEX (6-IN-1) LEDs
• Variable RGBAW+UV color mixing offers a seemingly unlimited color palette – Great for Stage or Wall Washing!
• 6 DMX Channel Modes: 3, 5, 6, 7, 8 or 11 channels
• 5 operational modes: Auto (Program Run), Sound Active, RGBAW+UV Dimmer, Static Color and DMX-512 Mode
• 3-Section Pixel control
• Patent Pending Quick Align (Magnetic)
• Beam Angle: 40 degrees
• Flicker Free operation @2200Hz
• 4-Button DMX LED Display
• 35 built-in Color Macros
• LED pulse & strobe effect
• Electronic Dimming: 0-100%
• Includes mounting brackets to mount on a wall or set on the ground
• Compatible with the ADJ UC-IR remote or Airstream IR iOS App(sold separately)
• Long Life LEDs (Rated at approximately 50,000 hrs.)
• Power Draw: 38W
• Linkable: DMX via 3-pin XLR cable; Power via IEC daisy-chain power link (Up to 25 UB 6H fixtures)
• Multi-voltage operation: AC 100V-240V 50/60Hz
• Dimensions (LxWxH): 22.5” x 2.5” x 3.75”/560 x 63 x 90mm
• Weight: 4 lbs./ 1.6 kg.
