With a rating of IP-65 and sturdy design this unit is well equipped to be used outdoors.
With 40 Prolight Opto RGBW 4-in-1 LEDs you will have absolutely no problem in colouring large areas. The 10° optic lenses generate a very strong beam and for more versatility you can always use one of the optional beam shapers: 20°, 40° or 15×60°. Besides these magnetic beam shapers, a barndoor or tophat are available as separate option as well.
The Helix S5000 is compatible with the Helix 4000 because they use the same colour presets and personalities. On top of this the Helix S5000 has Section control. Each unit has been equipped with WDMX by Wireless Solution Sweden and the 180° Flip-function gives you the opportunity to always place the unit in such a way that the cables and connectors are no longer visible. Rigging is also no issue because the unit comes complete with Quicklocks. We have even added a backlight touch display so you will be able to control your Helix S5000 under any circumstance where light is scarce. If you need to transport them, you can use our Premium line flightcase which will fit both models: Helix 4000 Q4 and Helix S5000.
SPECIFICATIONS
LED System: 40 x Prolight Opto RGBW 4-in-1 10W LEDs
Output@2m: 54000lux
Refreshrate: 3, 4, 6, 12kHz
Electrical
Power Supply: AC 100-240V 50/60 Hz
Power Consumption: 415W
Control
Control Mode: Auto/ built-in programs, Master/slave, DMX / RDM
DMX channels: 4, 6, 8, 20, 24ch
Optical system
Dimmer: 0-100%
Dim Curves: 4
Strobe: 0-20Hz
Beam Angle: 10° (optional 20°, 40°, 15×60°)
Tilt Angle: 0-180°
Physical
Dimensions: 532 x 320 x 122 mm
Weight: 9,5 Kg
Housing: Die-cast aluminium
Colour: Black
Power Connectors: Powercon True1
Data Connectors: XLR-HD 5-pin
Cooling: Forced-air
Safety
Operation temperature: -10~40°C
IP-Rating: IP-65
