Compact format audio mixer with 2, 4 or 6 mono input channels and a stereo line input. Each mono channel has a combo XLR/jack input with individually switchable mic/instrument impedance and +48V phantom power for the XLR. Input channels have High/Low EQ and Pan controls and mono channels also have Effects level to vary the amount of internal digital delay effect added for vocals or instruments. An internal player/recorder with backlit display can accept a USB memory stick containing compressed audio files in various formats or alternatively connect to a smart phone via BT wireless link. Output is delivered on a pair of balanced XLR connectors and offers very low noise operation for high quality studio or live performances.
Tech Specification:
-
Power supply
5Vdc 1A (adaptor included)
-
Output
Left + Right balanced XLR
-
Phantom power
+48V individually switchable (XLR inputs only)
-
Audio format
USB playback mp3, wma, ape, flac / record mp3 (48kHz 128kB/s)
-
Bluetooth version
2.1 + EDR
-
Power consumption max.
5W
-
Max. output level
3Vrms
-
Dynamic range
102dB
-
Frequency response
20Hz – 20kHz (±0.5B)
