Yamaha MG16X CV Analog Mixer


  • Compact 16-channel analog mixer
  • High-quality preamps provide clarity and detail with analog character
  • One-knob compressor, three-band channel EQ and SPX effects suite for tone shaping
  • Broad connectivity via RCA, XLR, and quarter-inch jack for routing audio

Out of stock

The Yamaha MG16X CV is a 16-channel analog mixer that provides the same functionality as their popular MG-XU series, without the USB interface functionality. It is perfect for settings and engineers who don’t feel the need to rely on USB connectivity for their mixers, and setups that don’t need computers. If you’re in need of flexible audio routing with pristine quality and the same fantastic effects section as Yamaha’s venerable SPX effects processors, the MG16X CV is an effective way to add all of these features to your mixing setup.

The channel strips available consist of eight mono channels with Yamaha’s clean, rich preamps, three-band EQ, and a one-knob compressor. These channels will accept XLR or quarter-inch jack connectors. Also included are two stereo channels with XLR inputs and phantom power, as well as three-band EQ. Finally, three sets of stereo channels that include high and low EQ shelves, as well as stereo RCA inputs for connecting to other external audio devices. Four AUX sends/returns per channel with a pre-fader switch add further routing options, and smooth faders allow for natural level control. All of these features combine to give you sixteen channels of audio that’s highly flexible. The MG16X CV is deal for compact, all-in-one live mixing, conferences, events, and installation.

Studio Grade Preamps

The preamp is the starting point when it comes to mixers and they are the most vital components for determining the quality of your mix. The mixers within the Yamaha MG series all feature a studio-grade class-A D-PRE preamp to deliver more power at a lower impedance. This premium preamp possesses an extremely wide frequency range and delivers a sound full of fat bass tones and incredibly smooth highs with little to no distortion. This pure platform allows you to get straight into the performance without needing to spend wasted time trying to ‘fix’ your mix.

Integrated Digital Effects

Featuring Yamaha’s outstanding SPX effects processor, users are given up to 24 editable digital effects to enhance their sound with. The built-in effects may provide additional depth to an overall sound or give a boost to a live band performance. With incredible reverb and delay effects, the mixer delivers a natural sound full of clarity.

Total Tonal Control

To add the little details to your overall mix, the MG12X includes 3-band equalisers on all mono channels to give you complete control. Along with a reliable high-pass filter, the analog mixer eliminates unwanted low-frequency noise for an astonishingly clean mix. Then, fine-tune dynamics with the one-knob compressor, and you have a pristine, professional result.

Wide Variety Of Connector

Every model in the MG series feature balanced XLR connectors on mono microphone, line channels and XLR equipped stereo channels. These mono inputs accept both mic and line level signals. Two stereo inputs have XLR and two phone connectors, accepting line level signals suitable for mono or stereo. The MG16X model features an additional stereo channel with a pair of jack sockets for LINE levels.

Durable Construction

Mixing consoles experience harsh environmental conditions such as excessive temperatures, humidity, unstable power supplies and the testing conditions of travel in general. This is why the MG series mixers have been built to last and withstand the trials and tribulations of a variety of testing situations. The console features an incredibly robust, powder-coated metal chassis that is designed for convection cooling as well as reducing operational noise. The circuit board and each component underneath is thoroughly protected with controlled placement of the chassis to ensure that no impact passes through the casing.

Included In The Box

  • 1 x Yamaha MG16X Analog Mixer
  • 1 x AC Adapter
  • 1 x Owner’s Manual
  • 1 x Technical Specifications Sheet


  • Studio-grade Discrete Class-A “D-PRE” Mic Preamps with an Inverted Darlington Circuit
  • High quality sound Op-amp
  • Switchable phantom power and PAD switch
  • Professional 1-knob compressors with LED Indicators
  • EQ and high-pass filters
  • Wide range of input and output connectors
  • LED level metering
  • Built-in SPX digital effects
  • Rugged, impact-resistant, powder-coated metal chassis
  • Integrated rack-ears for easy rack mounting
  • Universal power supply


  • Inputs: 16
    • 8 x Mono Mic/Line
    • 2 x Mono/Stereo Mic/Line
    • 2 x Stereo Line
  • Outputs:
    • 2 x Stereo
    • 1 x Monitor
    • 1 x Headphone
    • 4 x Aux Sends
    • 4 x Group
  • Phantom Power: 48V (Per Channel)
  • Total Harmonic Distortion: 0.03 Percent
  • Frequency Response: 20Hz – 20kHz, +0.5dB/-1.5dB
  • Equivalent Input Noise: -128dB
  • Residual Output Noise: -102dB
  • Crosstalk: -78dB
  • Power Requirements: 100V – 240V, 50Hz/60Hz
  • Power Consumption: 36W
  • Dimensions: 444mm x 130mm x 500mm (W x H x D)
  • Weight: 6.8kg
  • Product code: CMG16XCVUK
