Portable Column PA System with Mixer and Bluetooth black
- All-in-one column speaker for PA and monitor applications
- 1,000 watts peak Class-D system power offer high performance with a low weight
- Powerful bass reproduction with 3 x 6.5″ woofers
- Balanced mids thanks to the 8 x 3″ full-range speakers
- Precise and silky highs with 2 x 1″ high frequency drivers
- Increased range and wider coverage through the array arrangement
- Homogeneous dispersion pattern through a BEM-optimised tweeter wave guide
- Distortion-free sound even at the highest volume thanks to LD Systems DynX® DSP technology
- Full control through a 4-channel mixer including Bluetooth® Stereo Audio Streaming
- Two-piece column for compact transport
- Secure plug-and-play connection thanks to the wireless multi-pin mechanism
- A wide range of application options through dismountable columns
- Easy operation with presets for mono or stereo configuration
- Extensive and smart accessories for installation and transport
Specifications
General
Weight 24,9 kg
Color Black
Max. SPL (peak) 124 dB
Frequency response 50 – 20000 Hz
Dispersion (H x V) 120° x 20 °
Overall height 2030 mm
Woofer characteristics
Low/mid driver dimensions 3 x 6.5 “
Woofer size 3 x 165.1 mm
Woofer magnet Ferrite
Woofer brand Custom-made
Woofer voice coil 1.5 “
Woofer voice coil (mm) 38.1 mm
Cabinet construction Bass Reflex
Cabinet material 15 mm Plywood
Cabinet surface texture paint
Subwoofer width 285 mm
Subwoofer height 650 mm
Subwoofer depth 373 mm
Subwoofer weight 16.9 kg
Mid/Hi System
Midrange size 8 x 3 “
Midrange size 8 x 76.2 mm
Midrange magnet Ferrite
Midrange brand Custom-made
Midrange voice coil 1 “
Midrange voice coil 25.4 mm
Horn Waveguide
Tweeter dimensions 2 x1 “
Tweeter dimensions (mm) 25.4 mm
Tweeter magnet Neodymium
Tweeter brand Custom-made
Tweeter voice coil 1 “
Tweeter voice coil (mm) 25.4 mm
Loudspeaker inputs
1
Speaker input connections
Custom-made multipin
Cabinet construction mid/high
Closed
Mid/Hi system cabinet material
Aluminium
Mid/Hi system cabinet surface
HD coating
Mid/Hi system width
96 mm
Mid/Hi system height
620 / 730 mm
Mid/Hi system depth
104 mm
Mid/Hi system weight
5.4 / 2.6 kg
Amplifier module (integrated in subwoofer)
Amplifier Class D
Amplifier output system (RMS) 500 W
Amplifier output system (peak) 1000 W
Protection circuits DC protection, Multiband limiter, short circuit, thermal overload
Cooling Convection
Operating Temperature 0 – 40 °C
Humidity Range 10% to 80%, (non-condensing)
Controls
Bluetooth switch, Hi-Z Level, Line level, Main level, Mono/stereo switch, MP3/Bluetooth Level, Power, Sub level
Indicators
Limit, mono, On, Protect (protection circuit engaged), Setup, Signal, stereo
Power connector IEC power cable (included)
Operating voltage 100 – 120 V / 50 – 60 Hz or 200 – 240 V / 50 – 60 Hz (automatic switching)
Power consumption Off / On / Max. 0/11/600 W
Line inputs 2 x stereo
Line input connectors RCA, XLR/6.3 mm jack
Line outputs 1 x direct out
Line output connectors XLR
Mic inputs 1
Mic inputs XLR/6.3 mm jack
MP3 inputs 1
MP3 input connectors 3.5 mm jack
Hi-Z inputs 1
Hi-Z input connectors 6.3 mm jack
Loudspeaker outputs 1
Speaker output connections
Custom-made multipin
DSP characteristics
Bit depth AD/DA converter
24 bit
Internal sampling frequency
48 kHz
Signal/noise ratio
100 dB
