AV:Link 4K HDMI Splitter 1×8

4K HDMI Splitter

• Simple connection and installation
• Gold plated HDMI connectors for optimum signal transfer
• Supports HDMI v1.4b resolutions up to 3840 x 2160 @ 30Hz
• UK power adaptor supplied
• Ideal for entertainment, hospitality and other commercial venues requiring multiple display feeds from a single HDMI source
• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats

• • Weight

    1.05 kgs

  • SKU

    128828

• HDMI version

  v1.4b

• Video resolution

  Up to 3840 x 2160 @ 30Hz

• Display colours

  8/10/12bit deep colour

• Audio format

  DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD

• Max. bandwidth

  340MHz

• Max. baud rate

  3.4Gbps

• Transmission distance

  25m max HD or 16m max 4K (15m input/10m output @ 1080p and 8m input/output @ 4K)

• Operating temperature range

  -15¡C to +55¡C

• HDCP version

  1.4 (input only)
