The HEX70SL-KIT 4K HDBaseT™ extender set offers market leading features in a slimline chassis. The product delivers HDMI, Bi-directional IR and Bi-directional PoC up to lengths of 70m.
Features
- Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
- Enhanced slimline chassis
- Extends HDMI 1080p up to a distance of 70m over a single CAT cable
- Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
- Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
- Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
- Bi-directional IR pass-through
- Supplied with Blustream IR Receiver and Emitter
- Supports Bi-directional PoC to power extenders from either Transmitter or Receiver end
- HDCP 2.2 Compliant with Smart EDID management
| Video Input Connectors (TX): | 1 x HDMI Type A, 19-pin, female | Video Output Connectors (TX): | 1 x HDBaseT™ RJ45 connector |
|---|---|---|---|
| IR Input Ports (TX): | 1 x 3.5mm stereo jack | IR Output Ports (TX): | 1 x 3.5mm mono jack |
| EDID (TX): | Pin hole button | Video Input Connectors (RX): | 1 x HDBaseT™ RJ45 connector |
| Video Output Connectors (RX): | 1 x HDMI Type A, 19-pin, female | IR Input Ports (RX): | 1 x 3.5mm stereo jack |
| IR Output Ports (RX): | 1 x 3.5mm mono jack |
Box Contents
1 x HEX70SL-TX
1 x HEX70SL-RX
1 x 12V/1A DC Power Supply
1 x IR Emitter
1 x IR Receiver
2 x Mounting Kit
1 x Quick Reference Guide
